What’s New in The Modal Shop’s Rental Inventory?
New and Notable Products for Your Testing
Our Rental Team is always looking for new products to add to our rental inventory so that you can have the testing tools you need at your fingertips.
356A19/NC
Miniature, High Frequency Low-Outgassing ICP® Triaxial Accelerometer with TEDS
356A19/NC is a lightweight triaxial sensor capable of high frequency measurements to 13 kHz, low outgassing attached cable, and TEDS capability – ideal for structural testing, HALT/HASS and more.
Key Specs
- 4 gram mass
- ± 500 g pk measurement range
(10 mV/g sensitivity) - 0.6 Hz to 15 kHz (± 10%) frequency range
- Adhesive Mount
- Integral 5 ft (1.5 m) cable to 1/4-28 4-pin jack
Ideal for
- Modal and structural analysis
- Thermal vacuum environments
- Vibration testing of satellites
- Automotive ICE and EV powertrain development
- Vehicle systems NVH
Related items in our rental pool
- 356A19 - includes 5 ft (1.5 m) breakout cable to BNC
Learn More
TLD356A03/NC
Ultra-miniature ICP® Triaxial Accelerometer with TEDS
This is an upgrade to existing popular 356A03 model with the addition of TEDS functionality to reduce setup time and minimize potential errors due to manual sensitivity input.
Key Specs
- 1 gram mass
- ± 500 g pk measurement range
(10 mV/g sensitivity) - 2 Hz to 8 kHz (± 5%) frequency range*
- Adhesive mount
- Integral 5 ft (1.5 m) cable to 1/4-28 4-pin jack
* Varies by axis
This ultra-miniature accelerometer is ideal for
- Electronic device design validation
- Automotive systems development
- Modal and structural analysis
- ESS and HALT/HASS testing
- Space restricted installations
- Device and small component qualification testing
- General purpose vibration testing
Related items in our rental pool
- TLD356A03 - includes 5 ft (1.5 m) breakout cable to BNC
- 356A03/NC - without TEDS, no breakout cable supplied
Learn More
354B04 and 354B05
Case Isolated Triaxial ICP® Accelerometers
Case isolation reduces noise caused by high magnetic fields. Through-hole sensors install with a single fastener, allowing 360-degree rotation to align specific axes. Low outgassing and hermetically sealed for use under a vacuum.
Key Specs
- ± 500 g pk measurement range (354B04);
± 50 g pk measurement range (354B05) - 10 mV/g sensitivity (354B04);
100 mV/g sensitivity (354B05)
- 0.4 Hz to 10 kHz (± 5%) frequency range
- Titanium housing
- TEDS 1.0 Compliance
- Side 1/4-28 4-pin jack
- Includes hardware for 6-32 and M3 mounting
Case isolated accelerometers are ideal for
- Vibration measurements in the presence of electrical noise
- Flight and ground vibration testing
- Environmental Stress Screening (ESS)
- Modal analysis
HTJ356A43
Miniature, Ground Isolated, ICP® Triaxial Accelerometer with TEDS
The "HTJ" is a variant on the popular ±500 g pk adhesive mount miniature triaxial ICP® accelerometer with TEDS, ground isolation to reduce electrical noise and ground loops, and an extended temperature range to 325°F (163°C).
Key Specs
- 5.7 gram mass
- ± 500 g pk measurement range
(10 mV/g sensitivity) - 1.1 Hz to 10 kHz (± 10%) frequency range
- Adhesive mount
- Titanium housing
- Side 1/4-28 4-pin jack
Ideal for
- Modal and structural analysis
- NVH studies
- Space restricted installations
- Drop and package testing
- Small component qualification testing
Related items in our rental pool
- 356A43 – TEDS, 4 gram mass, 0.4 Hz to 10 kHz (±10%) frequency range
- J356A43 – TEDS, Ground Isolation, 5.7 gram mass, 0.4 Hz to 10 kHz (±10%) frequency range
Learn More
356A06/NC and 356A09/NC
Ultra-miniature Triaxial Accelerometers
The very popular 1 gram mass 356A01/NC and 356A03/NC lose their attached cable and gain an 8-36 4-pin connector to mate with a breakout cable to fit any application.
Key Specs
- ± 1000 g pk measurement range (356A06/NC);
± 500 g pk measurement range (356A09/NC) - 20 mV/g sensitivity (356A06/NC);
10 mV/g sensitivity (356A09/NC)
- 2 Hz to 8 kHz (± 5%) frequency range*
- Side mini 8-36 4-pin connector
* Varies by axis
Ideal for
- NVH studies
- Space-restricted installations
- Small component qualification testing
Related items in our rental pool
- 356A06 – includes 10 ft (3 m) breakout cable to BNC
- 356A09 – includes 10 ft (3 m) breakout cable to BNC
Learn More
356A04/NC and 356A05/NC
Miniature ICP® Accelerometers with Integral Cable
High overload limit prevents sensor damage, extremely small size minimizes mass loading, and a wide frequency range allows for broader testing capabilities.
Key Specs
- 0.8 gram mass
- ± 5000 g pk measurement range (356A04/NC);
± 20000 g pk measurement range (356A05/NC) - 1 mV/g sensitivity (356A04/NC);
0.25 mV/g sensitivity (356A05/NC)
- 1.2 Hz to 10 kHz (± 5%) frequency range
- integral 5 ft (1.5 m) cable to 1/4-28 4-pin connector
Ideal for
- Environmental Stress Screening (ESS)
- Electronic board testing
- Mobile electronics drop testing
- Small component shock testing
Related items in our rental pool
- 356A04 – includes 5 ft (1.5 m) breakout cable to BNC
- 356A05 – includes 5 ft (1.5 m) breakout cable to BNC
Learn More
354C02
Ring-style, Through-hole Mounted Triaxial ICP® Accelerometer
This triaxial accelerometer allows for easy mounting with one socket head cap screw. Ground Isolated titanium housing.
Key Specs
- 15.5 gram mass
- ± 500 g pk measurement range (10 mV/g sensitivity)
- 0.5 Hz to 4 kHz (± 5%) frequency range*
- Includes 10-32 UNF-2A SHCS for mounting
* Varies by axis
Ideal for
- Any installation for which precise sensor orientation is essential
- Installations with signal noise from electrical interference or poor grounding
350B43/NC and 350B42/NC
High Shock Pyromid Triaxial ICP® Accelerometers
Mechanically isolated, electrically filtered ICP® accelerometer avoids electrical noise and ground loops
Key Specs
- 27 gram mass
- ±10000 g pk measurement range (350B43/NC) and
±50000 g pk measurement range (350B42/NC) - 0.5 mV/g sensitivity (350B43/NC);
0.1 mV/g sensitivity (350B42/NC) - 0.4 Hz to 10 kHz (±1 dB) frequency range
- Side 1/4-28 4-pin jack
- Includes 1/4-28 UNF-2B mounting bolt
* Varies by axis
Ideal for
- Nearfield and far-field pyroshock
- Shaker shock
- Explosive bolts and stage separation
- Pile driver monitoring
- Body armor and helmet testing
- High-shock metal-to-metal impact
Related items in our rental pool
- 350B42 – includes 5 ft (1.5 m) breakout cable to BNC
- 350B43 – includes 5 ft (1.5 m) breakout cable to BNC
Learn More
